Weslock Bordeau Lever Collection

by Weslock
Save 45%
$55.90
$30.75

Features

  • 5-Pin Cylinder
  • Weslock keyway (optional Schlage Keyway)
  • Exceeds ANSI A 156.2 Grade II lock standards
  • Cylindrical Door Locks
  • ADA compliant levers
  • Removable knobs/levers prevents scratching during installation
  • Pre-installed screws concealed behind snap-on rosette
  • Panic-Proof Keylock/Privacy– one turn of interior knob/lever unlocks & opens door
  • Push Button locking in rosette
  • Zinc diecasted levers
  • All brass rosettes
  • Adjustable latches 2-3/8” or 2-3/4” with removable faceplates
  • Fits doors prepared with 2-1/8” cross hole & 1” edge hole
  • Adjusts to door thickness from 1-3/8” to 1-3/4”

Product Specifications - Click Here

Functions

  • Hall/Closet (Passage) Right Handed - 600U RH - Levers free on both sides - Normally used on hallway and closets
  • Hall/Closet (Passage) Left Handed - 600U LH - Levers free on both sides - Normally used on hallway and closets
  • Bed/Bath (Privacy) Right Handed - 610U RH - Levers are locked/unlocked from inside by turn button or outside by emergency key.  Normally used on bathrooms and bedrooms.
  • Bed/Bath (Privacy) Left Handed - 610U LH - Levers are locked/unlocked from inside by turn button or outside by emergency key.  Normally used on bathrooms and bedrooms.
  • Keyed Entry - Keyed Different Right Handed - 640U KD RH- When keyed different the locks will have different keys. Each lock has its own unique key and can not be opened by the other keys from the same locks.  Levers are locked/unlocked from inside by turn button or outside by key.  Normally used on exterior doors.
  • Keyed Entry - Keyed Different Left Handed - 640U KD LH - When keyed different the locks will have different keys. Each lock has its own unique key and can not be opened by the other keys from the same locks.  Levers are locked/unlocked from inside by turn button or outside by key.  Normally used on exterior doors.
  • Keyed Entry - Keyed Alike Right Handed - 640U KA RH - When keyed alike, all locks in a set can be opened with the same key.  Levers are locked/unlocked from inside by turn button or outside by key.  Normally used on exterior doors.
  • Keyed Entry - Keyed Alike Left Handed - 640U KA LH - When keyed alike, all locks in a set can be opened with the same key.  Levers are locked/unlocked from inside by turn button or outside by key.  Normally used on exterior doors
  • Half Dummy Right Handed- 605U RH- Single sided lever is stationary for Right Handed Door
  • Half Dummy Left Handed- 605U LH- Single sided lever is stationary for Left Handed Door
