The Single-Source Hardware Schedule & Submittal Guide: How to Prevent Mismatches and Protect Ship Windows

The 10 Fields That Prevent Mismatches and Delays

1. Project / Phase ID — Which project or phase this opening belongs to

2. Opening ID — A unique identifier for each door (e.g., "Unit 3 - BR2")

3. Door Type / Opening Type — Entry, bedroom, bathroom, mechanical, common area, etc.

4. Handing (LH/RH + Swing Note) — Left-hand (LH), Right-hand (RH), Left-hand Reverse (LHR), or Right-hand Reverse (RHR).

5. Function — Privacy, passage, keyed entry, dummy, etc.

6. Finish Code — Standardized finish designation (e.g., "619" for satin nickel)

7. Hinge/Strike Requirements — Basic hinge size, finish match, strike plate needs

8. Code Flags — ADA, fire-rated, egress notes as applicable

9. Keying Note — Keyed-alike (KA) group, master key (MK) placeholder, cylinder notes

10. Logistics & Logic — Ship window, partial/complete shipment policy, and Package ID. — Target delivery date, whether partial ships are acceptable, and the package identifier that ties this opening to a standard set

"If it isn't on the schedule, assume it will be wrong."

Who Fills Each Field and Why It Matters

When every field is populated before ordering, the schedule becomes a contract between the project team and the supplier. Missing fields invite assumptions—and assumptions invite callbacks.

One Completed Schedule Row (Example)

This completed row is the standard. If any opening cannot be filled to this level, the risk is known early—before procurement and before installers are waiting.

Ready to turn your schedule into a quote? Request a custom quote with your schedule, quantities, and ship window.

A Finish and Handing Map Removes Installer Confusion

Two fields cause more jobsite confusion than any others: finish and handing. A finish/handing map makes both unmistakable.

Handing Basics

Door handing describes which side the hinges are on and which way the door swings. The standard convention:

• Left-Hand (LH): Standing on the outside (or 'secure' side) of the door, the hinges are on the left and the door pushes away from you.

• Right-Hand (RH): Standing on the outside, the hinges are on the right and the door pushes away from you. Note: Always determine handing from the exterior or 'push' side to remain consistent with BHMA standards.

• Left-Hand Reverse (LHR): Hinges on the left, door opens toward you

• Right-Hand Reverse (RHR): Hinges on the right, door opens toward you

The key question: Stand on the exterior side (or the "push" side for interior doors). Which side are the hinges on? That determines the hand.

Common Exceptions to Watch

• Pocket doors: Handing doesn't apply in the traditional sense; specify "pocket" and note the pull style

• Dutch doors: Document handing for the primary leaf and note the configuration

• Double doors: Specify active leaf handing and note if both leaves are active

When finish codes are standardized and handing is documented per opening, installers stop guessing. The hardware shows up, matches the schedule, and goes on the door.

For finish options across major brands, explore collections from Emtek, Baldwin, or Schlage to compare finish codes before finalizing the schedule.

Code Flags Constrain Set Selection Before Submittal

Code flags identify openings with requirements that limit hardware choices. Capturing these flags at the schedule stage prevents ordering hardware that fails inspection.

Three Common Code Flag Categories

ADA / Accessibility Requirements

Openings in accessible routes typically require lever hardware (not knobs) that can be operated with one hand without tight grasping, pinching, or twisting. The 2010 ADA Standards for Accessible Design remain the federal baseline; however, many jurisdictions have now adopted the ICC A117.1-2017 (or 2021/2024 editions) and the 2024 International Building Code (IBC). Ensure your hardware schedule accounts for local reach-range and 'operable parts' requirements which may be more stringent than federal 2010 standards.

Fire-Rated Assemblies

Fire-rated doors require listed and labeled hardware that preserves the assembly's integrity. Under NFPA 80 (2025 Edition), field modifications—such as drilling for new locks or prepping for different hinges—are strictly limited. Unauthorized field prep can void the fire label, requiring a costly field recertification by a listing agency (e.g., UL or Intertek). Strategy: Always confirm that the hardware specified on the schedule matches the factory door prep exactly; if changes are needed on-site, consult a certified Fire Door Assembly Inspector (FDAI) before drilling, though the authority having jurisdiction (AHJ) determines local requirements. For teams verifying listing and labeling requirements, UL's fire-rated doors guide offers practical context.

Egress Requirements

Exit doors and doors along egress paths may have specific hardware requirements—panic hardware, specific latching functions, or restrictions on double-keyed deadbolts. NFPA 101 (Life Safety Code) and model building codes accessed through ICC Digital Codes address egress, with local codes taking precedence.

How to Flag on the Schedule

Add a "Code Flags" column and use simple notation:

External References

These references support code flag identification and help teams confirm terminology. They do not replace project-specific code review.

• 2010 ADA Standards for Accessible Design (ADA.gov)

• NFPA 80 (Standard for Fire Doors and Other Opening Protectives) (NFPA)

• NFPA 101 (Life Safety Code) (NFPA)

• ICC Digital Codes (IBC/IRC access)

• ANSI/BHMA Standards Overview (Builders Hardware Manufacturers Association)

• UL Fire-Rated Doors and Hardware Overview (UL Solutions)

Important: This guide is educational and does not replace local code review. Verify project requirements with the AHJ and design team before finalizing hardware selections. Fire-rated openings require listed and labeled compatible components per applicable listings.

A Submittal Package Speeds Approvals and Protects Ship Windows

A submittal package compiles the documentation a reviewer needs to approve the hardware selection. A lean, complete package gets approved faster than a thick binder with missing pieces.

Include vs. Skip: Submittal Package Checklist

Executive Summary Template (copy-ready)

A one-page executive summary at the front of the submittal orients reviewers and speeds approval. Include:

Project Name & Phase: [Project identifier]

Hardware Scope: [X] total openings across [Y] unit types

Finish Palette: [List standardized finish codes and names, e.g., "619 Satin Nickel, 613 Oil Rubbed Bronze"]

Key Selections:

• Entry sets: [Function, brand/series if specified]

• Interior passage: [Function, brand/series if specified]

• Interior privacy: [Function, brand/series if specified]

• Specialty (pocket, barn, etc.): [As applicable]

Keying Approach: [Keyed-alike groups / Master key system / Construction keying needs]

Code Compliance Notes: [ADA openings: X qty / Fire-rated openings: Y qty / Egress openings: Z qty]

Ship Window Target: [Date or phase milestone]

Primary Contact: [Name, phone, email]

This single page tells the reviewer what to expect before they turn to the details.

Ship Windows Reduce Schedule Risk More Than Stock Badges

A "stock" badge on a product page means inventory exists today. It does not mean that inventory will ship in time for your install window. The distinction matters.

"Visible stock status is not a ship window."

Stock Signal vs. Ship Window

A ship window is a commitment, not a snapshot. It accounts for order processing, packaging, transit time, and a buffer for the unexpected.

Building a Ship Window Strategy

Step 1: Identify critical path openings. Entry doors, fire-rated assemblies, and any opening that blocks subsequent trades go first. If the entry hardware isn't installed, the painter can't finish the jamb. If the fire-rated hardware isn't in, the inspector can't sign off.

Step 2: Back-calculate from install date. Work backward from when hardware must be on-site, ready for install. Include transit time, receiving/staging time, and at least a two-day buffer for shipping delays.

Step 3: Confirm availability at order time. "In stock" on Monday doesn't guarantee "in stock" on Friday. Confirm availability when placing the order, not when building the schedule.

Step 4: Decide on partial vs. complete shipping. Some projects tolerate partial shipments; others don't. Document the policy on the schedule so the supplier knows whether to hold and ship complete or release items as available.

As noted on the Express Hardware Direct site, in-stock items normally ship the same day if ordered before 12pm Central, and orders ship from multiple U.S. locations based on nearest inventory. But stock status at browsing time is not a ship commitment—confirm when ordering.

Have questions about lead times or availability? Submit a message for a quote with your target ship window.

Partial vs. Complete Ship: A Decision Tree

Not every project handles partial shipments the same way. Use this decision tree to document the policy before ordering.

Question 1: Is the opening needed to pass inspection or secure the building this week?

• Yes → Prioritize shipment for that opening type.

• No → Proceed to Question 2.

Question 2: Can the opening be installed to a usable state without the delayed component?

• No → Require complete ship for that opening to avoid stop/start labor.

• Yes → Proceed to Question 3.

Question 3: Will a partial ship create finish mismatch or keying inconsistency risk?

• Yes → Require complete ship (finish/keying integrity is the point of standardization).

• No → Proceed to Question 4.

Question 4: Will receiving partial shipments increase jobsite handling loss (missing parts, mixed boxes)?

• Yes → Choose complete ship or consolidate to fewer delivery events.

• No → Partial ship can be used as a schedule tool.

Document the decision on the schedule. Add a column for "Ship Policy" and note "Complete" or "Partial OK" per opening or per phase. When the supplier knows the policy upfront, they can plan accordingly.

A Package ID Field Connects the Schedule to One-Line-Item Ordering

Once the schedule is complete, the next step is mapping openings to package IDs. A package ID represents a standardized door hardware set—one line item that includes all components for that opening type.

Instead of ordering lever, rosette, strike, screws, and hinge separately for each bedroom door, a package ID bundles them: "PKG-BR-619" might represent "Bedroom set, passage function, satin nickel, standard prep."

How Package IDs Reduce Errors

Adding Package ID to the Schedule

The schedule defines requirements; packages execute them. When package IDs appear on the schedule, the order becomes a matter of counting: "12x PKG-BR-619, 6x PKG-BA-619, 4x PKG-ENT-619."

This approach—schedule to sets—is the bridge between documentation and procurement. For projects standardizing across multiple plans, explore door hardware options that can be grouped into finish-matched packages.

A Clean Quote Request Starts With the Schedule You Already Built

The hardware schedule isn't just for internal coordination. It's the fastest path to an accurate quote.

What to Include in a Quote Request

When requesting a bulk quote, include:

• The completed hardware schedule (or the key columns: opening ID, function, finish, handing, code flags)

• Quantities per opening type (e.g., "24 passage, 12 privacy, 6 keyed entry")

• Finish codes (standardized, not descriptions like "brushed silver")

• Functions (privacy, passage, keyed entry, dummy, etc.)

• Ship window (target delivery date or install milestone)

• Keying notes (keyed-alike groups, master key requirements, construction keying)

• Partial ship policy (complete only, or partial acceptable)

The more complete the request, the faster and more accurate the response.

What Slows Down a Quote

• Descriptions without finish codes ("something silver")

• Missing quantities ("a bunch of bedroom doors")

• No ship window ("whenever")

• Undefined keying ("we'll figure it out later")

A supplier can quote from a complete schedule in hours. A supplier working from incomplete information has to ask questions first—and every round trip adds days.

Next Step: From Schedule to Standardized Sets

The schedule is complete. The submittal package is ready. The next step is turning that documentation into standardized door hardware packages—preset bundles mapped to each opening type that ship complete and install without guesswork.

This is the bridge from planning to procurement: schedule fields become package IDs, package IDs become one-line-item orders, and one-line-item orders become finish-matched shipments that arrive on time.

Have your schedule ready? Request a custom quote and include your ship window and keying notes. The team at Express Hardware Direct can help map your schedule to standardized packages and confirm availability for your install timeline.

Express Hardware Direct supplies standardized, finish-matched door hardware sets for residential builders and GCs. We help you publish clean hardware schedules and ship complete kits—on time.

This guide is educational and does not replace local code review. Verify project requirements with the AHJ/design team, and confirm availability/lead times for your ship window before ordering.

Have your schedule ready? Request a custom quote and include your ship window and keying notes.

Additional Resources

• FAQs — Common questions about ordering, shipping, and returns

• Return Policy — Guidelines for returns and exchanges

• Terms of Service — Order terms and conditions

Disclaimer: This article is for general educational purposes. Code requirements (including accessibility, fire-rated openings, and egress) vary by jurisdiction and project conditions. Always confirm requirements with your local authority having jurisdiction (AHJ) and the door/hardware listings for your specific assemblies.
