Submittal Package Checklist for Door Hardware: What to Include and What to Skip

Hardware Schedule Excerpt: Finish, Handing, Function, and Opening ID

The hardware schedule excerpt is your anchor document. It tells the reviewer: "Here's every door, and here's exactly what goes on it." Include the opening ID, finish code, handing (left or right), and function (passage, privacy, keyed entry, etc.).

Without this, reviewers have to cross-reference multiple documents to verify consistency. That's where delays originate.

Component List by Opening (Or Package ID Mapping)

For projects using standardized packages, map each opening to a package ID. For custom specs, list components door by door. Either way, the goal is the same: show exactly what hardware is assigned to each opening so there's no ambiguity.

This is what prevents "approved schedule, wrong box" problems in the field.

Cut Sheets: Show the Exact SKU and Function (Not the Whole Catalog)

A cut sheet is a product data sheet showing the specific SKU, dimensions, function, and finish options. Include one cut sheet per unique item type. If you have 30 passage sets that are all identical, you need one cut sheet—not 30.

The precision matters. When requesting pricing or checking stock status, suppliers need either the part numbers or a description containing the item names, functions, and finishes. Your cut sheets should provide exactly that level of detail.

When referencing specific products, using consistent naming helps. For example, manufacturers like Schlage, Emtek, and Baldwin each have their own finish codes and nomenclature. Match your cut sheets to what's actually being ordered.

Finish Chart: Standard Codes, Where Used, and Exceptions

The finish chart maps finish codes to opening types. It should answer: "Where does Satin Nickel go? Where does Oil Rubbed Bronze go? Are there any exceptions?"

If one bathroom gets a different finish than the rest, flag it. Reviewers need to see that you've thought through consistency—and intentionally chosen any deviations.

Keying Matrix: KA/KD/MK and Door List

The keying matrix clarifies the cylinder plan. Which doors are keyed alike (KA)? Which are keyed different (KD)? Is there a master key (MK) system?

List every keyed opening and its designation. This prevents turnover risk—the last thing you want is a homeowner discovering their front door key opens their neighbor's garage.

Code Flags: Fire/Egress/Accessibility Notes (When Applicable)

If any openings require fire-rated hardware, panic hardware for egress, or ADA-compliant accessibility features, flag them explicitly. Local authority having jurisdiction (AHJ) requirements govern, so note where these apply and confirm compliance.

Substitution Rules: What Can Change Without Re-Submittal

Define what's pre-approved for substitution. Clarifying this upfront prevents delays when procurement realities hit.

Examples of allowed substitutions (verify with specific contract terms):

• Same brand, newer series with equivalent specs (if original is discontinued)

• Same function, same handing, same grade, same footprint

Examples requiring resubmittal:

• Function changes

• Handing changes

• Finish changes outside the approved finish chart

• Changes to any code-affected opening

Technical Note: Code flags (fire, egress, accessibility) must be captured when they apply. Local AHJ requirements govern—check your jurisdiction's specific requirements before finalizing.

What to Skip (Common 'Bloat' That Slows Approvals)

Not everything belongs in a submittal. Here's what to leave out:

The rule is simple: if it doesn't help the reviewer verify what's specified, cut it.

Executive Summary Cover Sheet Template (Use This on Every Submittal)

A one-page executive summary at the front of your packet sets expectations and reduces back-and-forth. Use this template:

DOOR HARDWARE SUBMITTAL — EXECUTIVE SUMMARY

Project: [Project Name]
Address: [Site Address]
Date/Version: [Date] / Version [#]
Submitted By: [Your Company Name]
Reviewer(s): [Name(s)]

Scope: [Number] openings across [Number] door types

Finishes:

• Primary: [Finish Code + Name]

• Secondary: [Finish Code + Name]

• Exceptions: [Note any one-offs]

Keying Approach:

• [ ] Keyed Alike (KA) — [List door groups]

• [ ] Keyed Different (KD) — [List doors]

• [ ] Master Keyed (MK) — [Describe system]

Substitution Rules: [What can be swapped without re-review]

Ship Window / Sequencing Notes: [Any timing dependencies]

Exceptions: [Anything that differs from the standard package]

Project Identifiers, Date/Version Control, and Reviewer List

Always include project name, address, submission date, version number, and who's reviewing. This sounds basic, but missing identifiers cause packets to get lost or misrouted.

Decision Points: Keying, Substitutions, Lead-Time Notes

Surface the key decisions upfront. What's the keying plan? What substitutions are pre-approved? Are there lead-time constraints that affect the review timeline?

'Exceptions' Box: Anything That Differs From the Standard Package

If one door gets special treatment—different finish, different function, upgraded trim—call it out. Exceptions hidden in page 37 of a thick packet get missed. Exceptions on page one get addressed.

Day-to-Day Application: Here's the 10-minute workflow: Print the checklist → Populate cover sheet → Attach only unique cut sheets → Run the match test (finish + function + handing agree everywhere). That's it. You're ready to submit.

Right-Size the Packet by Project Type

Single Home: Keep It to 5–12 Pages Total (Typical)

For a single-family residential project, your submittal should fit in a slim packet. Hardware schedule excerpt, component list, cut sheets for unique items, finish chart, keying matrix, and cover sheet. If you're pushing past 12 pages, you're probably including redundant material.

Multi-Unit: One 'Master Set' + Unit Variations and a Keying Appendix

Multi-family projects need a different approach. Create one master hardware set that applies to standard units, then document variations by unit type. Add a keying appendix that maps the master key system across all units.

Don't repeat the full packet per unit. One master packet with a short appendix for variations keeps the submittal reviewable.

When a Hardware Consultant Is Involved: How to Align Formats

If you're working with a hardware consultant, align on format before you start assembling. Different consultants have different templates. Getting on the same page upfront prevents reformatting headaches later.

Match their format, but keep your core rules non-negotiable: opening IDs must be consistent, the finish chart must be single-source, and the keying matrix must be explicit.

Reviewer-Proof QA Pass Before You Submit

The Top 7 Rejection Triggers (And the One-Line Fix for Each)

1. Missing finish code on schedule — Add finish column to every row

2. Handing not specified — Mark LH or RH for every opening

3. Cut sheet doesn't match specified SKU — Verify SKU on schedule matches cut sheet exactly

4. No keying matrix included — Add KA/KD/MK designations with door list

5. Old version pages mixed in — Use version numbers and purge outdated files

6. Code flags missing for fire-rated doors — Review plans for fire-rated openings and flag each

7. Substitution rules unclear — State what's pre-approved in cover sheet

The 'Match Test': Finish + Function + Handing Must Agree Everywhere

Before you submit, run the match test. Pick any opening at random. Does the finish on the schedule match the finish chart? Does the function match the cut sheet? Does the handing match the door swing shown on plans?

If anything disagrees, fix it. Mismatches are the number one source of review ping-pong.

Version Control: How to Prevent Old Pages From Resurfacing

Label every document with a version number and date. When you update, increment the version and delete old files from your submittal folder. Add version and date to the footer of every page so extracted or printed pages remain traceable.

Reviewers flagging issues from a page you already fixed is frustrating—and avoidable.

Consensus Kit — Who Checks What:

• GC: Schedule completeness + substitutions rule

• Designer: Finish intent + exceptions

• Installer/Super: Handing/function clarity

• AHJ/Reviewer: Code flags where applicable

Next Step (Optional): Turn the Approved Packet Into Clean Ordering

Save the Packet as Your 'Single Source of Truth' for Procurement

Once approved, your submittal becomes your ordering bible. Don't rebuild from scratch—use the approved schedule, finish chart, and component list to generate your purchase order. This prevents the spec-to-order drift that causes field problems.

If You Need a Quote: What Information to Send So You Don't Get Stuck

When requesting pricing, include part numbers or a description with item names, functions, and finishes. Missing details create back-and-forth that delays your quote and your order.

If you need help identifying SKUs or verifying finish availability, Contact Us for assistance. To browse finish and function examples from major manufacturers, explore options from Schlage.

FAQ

Do I need cut sheets for every opening or just unique items?

Just unique items. If you have 20 identical passage sets, include one cut sheet for that SKU. Duplicating the same sheet 20 times adds bulk without adding information.

What is a keying matrix and who provides it?

A keying matrix shows how locks are keyed across a project—which doors share keys (keyed alike), which have unique keys (keyed different), and whether there's a master key system. The GC or owner typically defines the keying plan; the hardware supplier or locksmith executes it.

How many pages should a residential door hardware submittal be?

For a typical single-family home, 5 to 12 pages is standard. Multi-unit projects run longer but should still be organized as a master set plus variations, not a monolithic document.

What's the fastest way to show finish consistency across the project?

A finish chart. Map each finish code to the opening types where it applies, note any exceptions, and you've given reviewers a one-page answer to "Is this consistent?"

What should I include for substitutions to avoid re-review?

State the substitution rules in your cover sheet. Define what can be swapped (equivalent SKU from same manufacturer, same finish code, same function) and what triggers re-review (different manufacturer, different finish, different function).

If it can't be reviewed in 10 minutes, it won't be approved fast. Build lean, check thoroughly, and your submittals will move through review instead of bouncing back.
